HS 420 VGPU

The HS 420 VGPU mid-tower case combines functional beauty with user-centric innovation. Designed by the HAVN team, this case is crafted to deliver superior GPU airflow, featuring a VGPU Mount Kit with a PCI Express® 5.0 riser cable. Its elegant panoramic housing, hybrid structure, optimized airflow, and smart cable management system make it the ultimate sanctuary for your gaming setup.

  • UniSheet heat-formed panoramic glass panel for front and side, engineered to be flatter and with a smaller radius to minimize visual distortion.
  • Enhanced thermal performance with custom ventilation, supporting up to 11 x 140mm fans and 420mm radiators on top and side.
  • Intuitive SimpliCable routing system and fan hub keep your cables neatly organized and discreetly hidden.
Sale price$269.00

Color: White





HAVN Hybrid Structure for optimal GPU cooling

The HS 420 VGPU has a dual-chamber design with balanced airflow and a traditional case size ratio, channeling cool air from the bottom intake directly onto the centrally positioned GPU.

GPU Centric Design

The HAVN Hybrid Structure places the GPU front and center, fully showcased behind the panoramic Unisheet glass. This design not only emphasizes your key components but also enhances GPU airflow for optimal performance.

Mirrored Airflow

An additional fan intake at the bottom of the rear panel channels cool air directly to your graphics card, perfectly balancing intake and exhaust. This ensures peak performance and helps maintain a cleaner, dust-free system.

Adjustable VGPU Bracket

With different GPU thicknesses, the vertical GPU bracket can be adjusted horizontally to optimize the GPU's distance to the glass air guide.

Cooling Power & Compatibility

The HS 420 VGPU accommodates up to eleven 140mm fans and supports 420mm radiators on both the top and side.

UniSheet heat-formed Glass Panel for Panoramic View

We've pushed production boundaries to achieve the smallest possible curve radius, minimizing visual distortion and offering a clear, uninterrupted view of your case's interior.

Unique SimpliCable Routing System

The SimpliCable routing system and fan hub feature top-to-bottom grooved guides, making cable management effortlessly clean and giving your setup a pristine, organized appearance.

Cable Management Re-Invented

Clever silicon pass-throughs with stabilizing clips allow for precision cable management.

Lightning-fast Riser Cable Included

The VGPU Mount Kit and PCI Express® 5.0 X16 riser cable allow you to showcase your hardware without compromising on performance.

Vibration Isolation

Every fan bracket is equipped with flexible rubber isolators to separate the bracket from the chassis, preventing resonance and ensuring a quieter operation.

Customization

Customizable space accommodates a combination of storage, fans, radiators, and portable displays (VESA mounting bracket included)

Displays

Fans

Drag

Product Specifications

Form Factor

Mid Tower

Material

SGCC sheet metal, tempered glass, ABS, Nylon, Silicon, Zinc alloy, NdFeB magnets

PC Case Dimensions (L x W x H)

541 x 259.5 x 547 mm

Net Weight

19 kg

Warranty

3 years

Front I/O

USB 3.2 Gen 2 Type-C x1

USB 3.2 Gen 1 Type-A x2

Audio Jack x1

Power & Reset Button x1

Motherboard Support

E-ATX (Max Width 277 mm) / ATX / M-ATX / Mini-ITX

Expansion Slots

6 horizontal, 4 vertical

Fan Support

Maximum Amount: 11

Top: 3 x 120 / 3 x 140 mm

Right: 3 x 120 / 3 x 140 mm

Bottom: 3 x 140 mm

Rear: 2 x 120 / 2 x 140 mm (Thickness Up to 30 mm)

Fan PWM Repeater

Channel: Total 12 ch

Location: Cable Management Tray x1

PSU shroud x1

CPU Tower Cooler Clearance

Up to 185 mm
(Recommended AIO Liquid Coolers)

Liquid Cooling Support

Top: 280 / 360 / 420 mm (Thickness: 65 mm, not overlapping with RAM)

Right: 280 / 360 / 420 mm (Thickness: 60 mm w/ GPU >317mm, 80 mm w/ top AIO)

Graphics Card Clearance

Length: Up to 470 mm

Width: 195 mm

Vertical GPU Support

4 Slots

PCI Express 5.0 Riser Cable Included

RAM Clearance

If the radiator thickness is greater than 65 mm: 420 mm - 32 mm / 360 mm - 43 mm

Power Supply Support

ATX / SFX / SFX-L PSUs

Length: Up to 220mm (Clearance - 290mm)

Storage

Right Fan Mount: 4 Storage Bays: 4 x 3.5'' / 8 x 2.5''

Cable Management Tray: 1 Storage Bay: 1 x 3.5'' / 2 x 2.5''

Storage Bay Included: 4x

Internal Display Support

VESA Mounting: 75 x 75 mm / 100 x 100 mm

Display Size: 14 in. (Max)

Location: Front Right Pillar

Dust Filter

Bottom: 1 (Removable)

Top: 1 (Built-in)

Right: 1 (Built-in)

Rear Bottom: 1 (Removable)

Fan Configuration Recommendations
